MINVEN 1000w/1500w
Laser cleaning machine
MINVEN 1000w/1500w is a new generation of laser non-contact cleaning high-tech products launched by ARCBRO. It does not damage the part matrix, no consumables, energy-saving and environmental protection, and efficiently removes resin, oil, stains, dirt, rust, plating and painting on the surface of coated workpieces, which can meet the complex Industrial processing field.
The cleaning requirements of styling and fine positioning can achieve higher cleaning effect and lower comprehensive cost of production efficiency.
1. Lightweight design: The cleaning head weighs about 1.9Kg (including bald head), which is small and portable, which is more conducive to long-term handheld operation.
2. Dust-proof seal design: independent modular design of the outer optical path, double-sealed dust-proof, effectively preventing dust and other pollutants generated by cleaning from entering the optical path and cleaning head to cause performance damage or damage.
3. Removable dust suction port: independent dust suction port design, the height and angle are flexibly adjustable, and the dust suction effect is good.
4. Automatic/handheld universal operation design: The upper cleaning head can be controlled by the handle switch to trigger the laser switch, or the laser switch can be controlled by a robot or CNC through an automated control interface.
5. Anti-interference design: Improve the anti-interference ability of the cleaning head through measures such as digital signal enhancement, signal line shielding layer, galvanometer packaging, and metal shielding shell design.
| Product name | Laser Clean Machine |
| Model | Minvan 1000w/15oow |
| POWER | 1000W/1500W |
| Cooling system | Air Cooling Fiber Laser Markng Machine |
| Laser source | IPG Raycus Max JPT |
| Operation method | Handheld/Automated |
| Laser working method | pulse |
| Pulse Width | 20ns-500ns adjustable |
| Maximum single pulse energy | 15mJ |
| Power adjustment range (%) | 10- 100 (gradient adjustable) |
| Laser wavelength | 1064nm |
| Scanning range (length * width) | Line type 1mm~300mm, continuously adjustable; |
| Scan rate | 10-6000mm/s |
| Focal length of field lens (mm) | 210mm (160mm~500mm optional) |
| Depth of focus | ≥±5mm |
| Washing head weight | About 1.9Kg (including isolator) |
| Total Weight | 150Kg |
Laser Clean Machine | Traditional cleaning machine | ||
Comparison item | Laser Clean | Chemical cleaning | Mechanical polishing | Ultrasonic washing |
working principle | Laser | Chemical cleaning agent | Sandpaper/Grinding Wheel | Dedicated cleaning fluid |
Contactless | Yes | No | No | No |
No damage to the workpiece | Yes | No | No | No |
Cleanliness | High cleanliness | Uneven | Uneven | Uneven |
Clear efficiency | Good | Low | Low | Low |
Accuracy | High controllable accuracy | Uncontrollable poor accuracy | Uncontrollable poor accuracy | Cannot specify range |
Green | Yes | No | No | Yes |
Manual operation | simple | complex | Protective measures | simple |
Consumables | No | Yes | Yes | Yes |
Mainly used in automobile manufacturing, mechanical processing, railway industry, electronic processing, cultural relic restoration, mold industry, shipbuilding industry, food processing, petrochemical industry and other industries.
